HJL36080SA - Square D 80A 600V 3 Pole Molded Case Circuit Breaker with 120V Shunt Trip

HJL36080SA

HJL36080SA is a Square D 3 pole molded case circuit breaker rated for 80 amps and 600 volts AC with a 120V shunt trip feature.This thermal magnetic breaker features long time and instantaneous trip functions, current limiting, and is suitable for reverse fed applications. It has a 65kA interrupting rating at 480V and includes line and load side lug terminals for feed-thru installation.

• Amperage: 80A
• Voltage: 600VAC, 250VDC
• Poles: 3
• Frame Type: HJL (PowerPact H)
• Trip Unit: Thermal Magnetic with Long Time and Instantaneous functions
• Interrupt Rating: 65kA at 480V AC
• Shunt Trip Voltage: 120V
• Mounting Type: Panel mount, feed-thru capable
• Suitable for reverse fed applications
• Line and load side lug terminals
• Non-interchangeable trip
• Certifications: Meets California Proposition 65

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Additional Information

complete with 110/130Vac shunt trip

Specifications

• Part Number: HJL36080SA
• Manufacturer : Schneider Electric
• Brand : Square D
• Category : Circuit Breaker
• Item Subcategory : Molded Case
• Family : Powerpact
• Type : HJL
• Voltage : 600
• Amperage : 80
• Phase : 3
• Poles : 3
• AIC rating : 65kA@480V
• Connection : Feed-Thru
• Functions : Long Time and Instantaneous Trip
• Frame Size : H Frame
• Temp Rating : 28-158 °F (-2-70 °C)
• Protection : Thermal Magnetic

Product Data

• Country of Origin : Mexico
• Dimensions : 6.4 in (163 mm) x 4.09 in (104 mm) x 3.4 in (86 mm) (Height x Width x Depth)
• Weight : 5
• Standards : UL, CSA, NEMA, NOM-003-SCFI-2000, IEC 60947-2
• Certification : UL, CSA, NOM
• Wire Size : AWG 14...AWG 3/0 aluminium/copper terminal
