Product Info
- Manufacturer:Schneider Electric
- Sub-Category:Molded Case
Description
HJL36050M72BC
HJL36050M72BC is a Square D Powerpact H Frame 50 Amp 3 Pole Motor Circuit Protector rated for 600V applications. This circuit breaker is designed for reliable motor protection and features a thermal magnetic trip unit for enhanced safety and performance.
- Manufacturer: Square D
- Series/Frame: Powerpact H Frame
- Amperage: 50 Amp
- Number of Poles: 3 Pole
- Maximum Voltage: 600V AC
- Mounting Type: Unit Mount
- Interrupt Rating: 25 kA
- Product Type: Motor Circuit Protector
- Terminal Type: Lugs
- Tripping Method: Thermal Magnetic
- Features: Alarm Switch, 80% Rated
- Certifications: UL 489 Listed, CSA, NEMA, NMX, VDE, BS, CCC, IEC, CE
Specifications
- Part Number: HJL36050M72BC
- Manufacturer : Schneider Electric
- Brand : Square D
- Category : Circuit Breaker
- Item Subcategory : Molded Case
- Family : Powerpact
- Type : HJL
- Voltage : 600
- Amperage : 50
- Phase : 3
- Poles : 3
- AIC rating : 65kA@480V
- Connection : Feed-Thru
- Functions : I - Instantaneous
- Temp Rating : 28-158 °F (-2-70 °C)
- Protection : Magnetic Only
Product Data
- UPC : 785901437543
- GTIN : 00785901437543
- Country of Origin : Mexico
- Dimensions : 6.4 in (163 mm) x 4.09 in (104 mm) x 3.4 in (86 mm) (Height x Width x Depth)
- Weight : 5
- Standards : UL, CSA, NEMA, NOM-003-SCFI-2000, IEC 60947-2
- Certification : UL, CSA, NOM
- Wire Size : AWG 14...AWG 3/0 aluminium/copper terminal
