HJD63B350 - Siemens 350 Amp 600VAC 3-Pole Molded Case Circuit Breaker, Thermal Magnetic, Bolt-On Frame HJD

HJD63B350

HJD63B350 is a Siemens 3-pole molded case circuit breaker rated for 350 amps and 600VAC, designed for reliable thermal magnetic protection.This Siemens Sentron series breaker features a bolt-on connection type, long time and instantaneous trip functions, and a high interrupting rating of 35kAIC at 600V and 65kAIC at 480V. It supports line and load side lug connections and is UL and IEC certified for safety and performance.

• Amperage: 350A
• Voltage Rating: 600VAC
• Poles: 3
• Frame Type: HJD
• Connection Type: Bolt-On
• Interrupt Rating: 35kAIC at 600V, 65kAIC at 480V
• Trip Unit: Thermal Magnetic with Long Time and Instantaneous Trip
• Terminal Connection: Line and Load Side Lug
• Certifications: UL, IEC
• Wire Gauge: AWG 3/0 to 500KCM Cu, AWG 4/0 to 500KCM Al
• Dimensions (LxWxH): 4 x 7.5 x 11 inches
• Temperature Rating: 40 °C

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Additional Information

This item does not included Lugs. If you would like lugs please reach out to a sales rep with wiring specs and we can help you with the lugs part number.

Specifications

• Part Number: HJD63B350
• Manufacturer : Siemens
• Brand : Siemens
• Category : Circuit Breaker
• Item Subcategory : Molded Case
• Family : Sentron Series
• Type : HJD
• Voltage : 600
• Amperage : 350
• Phase : 3
• Poles : 3
• AIC rating : 65kA@480V
• Connection : Bolt-On
• Functions : Long Time and Instantaneous Trip
• Frame Size : JD Frame
• Temp Rating : -13–158 °F (-25–70 °C)
• Protection : Thermal Magnetic

Product Data

• UPC : 783643213401
• GTIN : 00783643213401
• Country of Origin : Mexico
• Weight : 20.084
• Wire Size : AWG 3/0 to 500KCM, Cu, AWG 4/0 to 500KCM, Al
