HJD63B250 - Siemens 250A 600V 3-Pole Molded Case Circuit Breaker JD Frame Thermal Magnetic

HJD63B250

HJD63B250 is a Siemens 250 Amp, 600 Volt, 3-Pole molded case circuit breaker with a JD frame and thermal magnetic trip unit.This Siemens HJD63B250 circuit breaker features bolt-on mounting and is designed for high interrupting capacity applications. It meets UL 489 and IEC 60947-2 standards, with interrupt ratings of 100,000 A at 240V AC, 65,000 A at 480V AC, and 35,000 A at 600V AC. The breaker supports wire sizes from 3/0 AWG to 500 Kcmil using the TA2J6500 lug kit. It measures 7.5 inches wide, 11 inches high, and 5.44 inches deep, weighing approximately 20 lbs.

Key Specifications
• Amperage: 250A
• Voltage Rating: 600V AC
• Poles: 3
• Frame Type: JD (HJD)
• Mounting Type: Bolt On
• Interrupting Rating: 100kA @ 240V, 65kA @ 480V, 35kA @ 600V
• Trip Unit: Thermal Magnetic
• Wire Size Range: 3/0 AWG to 500 Kcmil (with lug kit)
• Certifications: UL 489, IEC 60947-2
• Dimensions: 7.5" W x 11" H x 5.44" D
• Weight: 20 lbs
At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.


Additional Information

This item does not included Lugs. If you would like lugs please reach out to a sales rep with wiring specs and we can help you with the lugs part number.




Specifications

• Part Number: HJD63B250
• Manufacturer : Siemens
• Brand : Siemens
• Category : Circuit Breaker
• Item Subcategory : Molded Case
• Family : Sentron Series
• Type : HJD
• Voltage : 600
• Amperage : 250
• Phase : 3
• Poles : 3
• AIC rating : 65kA@480V
• Connection : Bolt-On
• Functions : LI - Long-Time and Instantaneous
• Frame Size : JD Frame
• Protection : Thermal Magnetic



Product Data

• UPC : 783643213388
• GTIN : 00783643213388
• Country of Origin : Mexico
• Weight : 11.332
