HJD63B225 - Siemens 225A 600V 3-Pole Thermal Magnetic Circuit Breaker JD Frame

HJD63B225

HJD63B225 is a Siemens 225 Amp, 600 Volt, 3-Pole thermal magnetic circuit breaker designed for high interrupting capacity applications.This Siemens HJD63B225 circuit breaker features a JD frame with bolt-on mounting, thermal magnetic trip unit, and an interchangeable trip design. It supports a 225 Amp rating at 40°C, 600 Volt AC operation, and offers interrupting ratings of 100,000 A at 240V, 65,000 A at 480V, and 35,000 A at 600V. The breaker measures 7.5 inches wide by 11 inches high by 5.44 inches deep and weighs approximately 20 lbs. It is UL 489 certified and suitable for use in NEMA Type 12 enclosures.

Key Specifications
• Amperage: 225A
• Voltage: 600V AC
• Poles: 3
• Frame Type: JD (HJD)
• Mounting Type: Bolt On
• Interrupting Rating: 100kA @ 240V, 65kA @ 480V, 35kA @ 600V
• Trip Unit: Thermal Magnetic, Interchangeable
• Dimensions: 7.5" W x 11" H x 5.44" D
• Weight: 20 lbs
• Certifications: UL 489

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Additional Information

This item does not included Lugs. If you would like lugs please reach out to a sales rep with wiring specs and we can help you with the lugs part number.

Specifications

• Part Number: HJD63B225
• Manufacturer : Siemens
• Brand : Siemens
• Category : Circuit Breaker
• Item Subcategory : Molded Case
• Family : Sentron Series
• Type : HJD
• Voltage : 600
• Amperage : 225
• Phase : 3
• Poles : 3
• AIC rating : 65kA@480V
• Connection : Bolt-On
• Functions : LI - Long-Time and Instantaneous
• Frame Size : JD Frame
• Protection : Thermal Magnetic

Product Data

• UPC : 783643213371
• GTIN : 00783643213371
• Country of Origin : Mexico
• Weight : 20.238
• Certification : UL
