HJA36080YP - Square D PowerPact H 80A 3-Pole Molded Case Circuit Breaker 600V 65kA@480V

HJA36080YP

HJA36080YP is a Square D PowerPact H-Frame molded case circuit breaker designed for reliable protection in commercial and industrial electrical systems. This 3-pole, 80 amp breaker operates at 600V and features a high interrupt rating for robust circuit protection. The HJA36080YP is part of the PowerPact H series, offering thermal magnetic trip technology for overload and short circuit protection. It is suitable for panelboard and switchgear applications, providing dependable performance and safety in demanding environments.

• Part Number: HJA36080YP
• Manufacturer: Square D
• Series/Frame: PowerPact H
• Amperage: 80A
• Voltage: 600V
• Poles: 3
• Interrupt Rating: 65kA @ 480V
• Mounting Type: Bolt-On
• Breaker Type: Molded Case
• Trip Unit: Thermal Magnetic
• Certifications: UL 489, CSA 22.2
• Weight: 4.54 kg

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: HJA36080YP
• Manufacturer : Schneider Electric
• Brand : Square D
• Category : Circuit Breaker
• Item Subcategory : Molded Case
• Voltage : 600
• Amperage : 80
• Phase : 3
• Poles : 3
• AIC rating : 65kA@480V
• Connection : I-Line Style Plug-In
• Functions : LI - Long-Time and Instantaneous
• Temp Rating : 28-158 °F (-2-70 °C)
• Protection : Thermal Magnetic

Product Data

• UPC : 3606486282687
• Country of Origin : Mexico
• Dimensions : 6.4 in (163 mm) x 4.09 in (104 mm) x 3.4 in (86 mm) (Height x Width x Depth)
• Weight : 5
• Standards : UL, CSA, NEMA, NOM-003-SCFI-2000, IEC 60947-2
• Certification : UL, CSA, NOM
• Wire Size : AWG 14...AWG 3/0 aluminium/copper terminal
