HJA36070UA - Square D PowerPact H 70A 3-Pole 600VAC I-Line Thermal Magnetic

HJA36070UA

HJA36070UA is a Square D PowerPact H series molded case circuit breaker designed for industrial and commercial power distribution applications.

This 3-pole thermal magnetic circuit breaker features a 70-amp continuous current rating at 600VAC with I-line plug-in mounting for seamless integration into I-line panelboards. The breaker incorporates long-time and instantaneous trip functions with an 800-amp magnetic hold current and 1450-amp trip setting. It supports ABC phase connection and is suitable for reverse-fed applications. The unit meets an 80% continuous current rating standard and is constructed with a durable molded case design.

• Amperage: 70A
• Voltage: 600VAC
• Poles: 3
• Series: PowerPact H (H-Frame)
• Mounting: I-Line plug-in
• Trip Unit: Thermal-magnetic with LI (Long-Time and Instantaneous) functions
• Interrupt Rating: 25kA at 600VAC
• Phase Connection: ABC
• Magnetic Hold Current: 800A
• Trip Current: 1450A
• Certifications: UL 489, CSA, NEMA, IEC, VDE, CE marked

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: HJA36070UA
• Manufacturer : Square D
• Brand : Square D
• Category : Circuit Breaker
• Item Subcategory : Molded Case
• Family : Powerpact
• Type : HJA
• Voltage : 600
• Amperage : 70
• Phase : 3
• Poles : 3
• AIC rating : 65kA@480V
• Connection : I-Line Style Plug-In
• Functions : LI - Long-Time and Instantaneous
• Protection : Thermal Magnetic

Product Data

• Weight : 5
