HJA260902 - Square D 90A 2 Pole 600VAC I-Line Thermal Magnetic Circuit Breaker

HJA260902

HJA260902 is a Square D 2 pole thermal magnetic molded case circuit breaker rated for 90 amps and 600VAC voltage. It is designed for reliable circuit protection in industrial and commercial applications.HJA260902 features a PowerPact H-frame with I-Line plug-in mounting, providing a breaking capacity of 25kA at 600VAC. It includes thermal magnetic trip technology with 80% continuous current rating and complies with UL, CE, IEC, and CSA certifications. The breaker supports 250/500VDC and has a magnetic trip current of 1450A, suitable for protecting electrical systems from overloads and short circuits.

Key Specifications
• Amperage: 90 Amps
• Voltage: 600VAC, 250/500VDC
• Poles: 2
• Mounting Type: I-Line plug-in
• Interrupt Rating: 25kA @ 600VAC
• Frame/Series: PowerPact H-frame
• Trip Unit: Thermal Magnetic
• Continuous Current Rating: 80% AC
• Certifications: UL, CE, IEC, CSA
• Magnetic Trip Current: 1450A
• Dimensions: 9.73 in H x 2.94 in W x 4.8 in D
• Ambient Temperature: 40°C max

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: HJA260902
• Manufacturer : Schneider Electric
• Brand : Square D
• Category : Circuit Breaker
• Item Subcategory : Molded Case
• Family : Powerpact
• Type : HJA
• Voltage : 600
• Amperage : 90
• Phase : 1
• Poles : 2
• AIC rating : 65kA@480V
• Connection : I-Line Style Plug-In
• Functions : Long Time and Instantaneous Trip
• Frame Size : H Frame
• Temp Rating : -13–158 °F (-25–70 °C)
• Protection : Thermal Magnetic

Product Data

• Country of Origin : Mexico
• Dimensions : 6.4 in (163 mm) x 4.09 in (104 mm) x 3.4 in (86 mm) (Height x Width x Depth)
• Weight : 3.999
• Standards : UL, CSA, NEMA, NOM-003-SCFI-2000, IEC 60947-2
• Certification : UL, CSA, NOM
• Wire Size : AWG 14...AWG 3/0 aluminium/copper terminal
