HJA260802 - Square D 80A 2 Pole 600VAC PowerPact H I-Line Thermal Magnetic Circuit Breaker 25kA Interrupt

HJA260802

HJA260802 is a Square D PowerPact H I-Line thermal magnetic molded case circuit breaker rated for 80 amps and 600 volts AC with 2 poles.This circuit breaker features an interrupt rating of 25kA at 600VAC, 65kA at 480VAC, and 100kA at 240VAC, designed for robust protection in industrial and commercial electrical systems. It is a current limiting breaker with an 80% rated trip unit, suitable for I-Line panelboards and switchboards. The breaker is UL, CSA, and CE certified, ensuring compliance with industry safety standards.

Key Specifications
• Amperage: 80 Amps
• Voltage: 600 VAC
• Poles: 2
• Mounting Type: I-Line Plug-In
• Interrupt Rating: 25kA @ 600VAC, 65kA @ 480VAC, 100kA @ 240VAC
• Series/Frame: PowerPact H
• Trip Unit: Thermal Magnetic, 80% rated
• Certifications: UL Listed, CSA, CE
• Phase: Single Phase
• Type: Molded Case Circuit Breaker
At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.


Specifications

• Part Number: HJA260802
• Manufacturer : Schneider Electric
• Brand : Square D
• Category : Circuit Breaker
• Item Subcategory : Molded Case
• Family : Powerpact
• Type : HJA
• Voltage : 600
• Amperage : 80
• Phase : 1
• Poles : 2
• AIC rating : 65kA@480V
• Connection : I-Line Style Plug-In
• Functions : Long Time and Instantaneous Trip
• Temp Rating : -13–158 °F (-25–70 °C)
• Protection : Thermal Magnetic



Product Data

• UPC : 785901697831
• GTIN : 00785901697831
• Country of Origin : Mexico
• Dimensions : 6.4 in (163 mm) x 4.09 in (104 mm) x 3.4 in (86 mm) (Height x Width x Depth)
• Weight : 3.999
• Standards : UL, CSA, NEMA, NOM-003-SCFI-2000, IEC 60947-2
• Certification : UL, CSA, NOM
• Wire Size : AWG 14...AWG 3/0 aluminium/copper terminal
