HJA260702 - Square D 70A 2-Pole 600V Thermal Magnetic Circuit Breaker

HJA260702

HJA260702 is a 2-pole molded case circuit breaker rated for 70 amps at 600 volts AC with thermal-magnetic tripping mechanism.

This PowerPact H series breaker features I-Line style plug-in connection for use in Class 611/612 panelboards and switchboards. The breaker is current-limiting type and provides reliable protection for industrial and commercial power distribution applications. It is designed for thermal-magnetic operation and carries UL, CSA, and CE approvals.

• Amperage: 70A
• Voltage: 600V AC
• Poles: 2
• Tripping Mechanism: Thermal-Magnetic
• Interrupt Rating: 25kA at 600VAC
• Series: PowerPact H
• Connection Type: I-Line Style Plug-In
• Wire Size: 14-3/0 AWG
• Type: Molded Case, Current-Limiting
• Certifications: UL, CSA, CE

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: HJA260702
• Manufacturer : Schneider Electric
• Brand : Square D
• Category : Circuit Breaker
• Item Subcategory : Molded Case
• Family : Powerpact
• Type : HJA
• Voltage : 600
• Amperage : 70
• Phase : 1
• Poles : 2
• AIC rating : 65kA@480V
• Connection : I-Line Style Plug-In
• Functions : Long Time and Instantaneous Trip
• Frame Size : H Frame
• Temp Rating : 28-158 °F (-2-70 °C)
• Protection : Thermal Magnetic

Product Data

• UPC : 785901795759
• GTIN : 00785901795759
• Country of Origin : Mexico
• Dimensions : 6.4 in (163 mm) x 4.09 in (104 mm) x 3.4 in (86 mm) (Height x Width x Depth)
• Weight : 3.999
• Standards : UL, CSA, NEMA, NOM-003-SCFI-2000, IEC 60947-2
• Certification : UL, CSA, NOM
• Wire Size : AWG 14...AWG 3/0 aluminium/copper terminal
