HJA260602 - Square D 60A 600V 2 Pole I-Line PowerPact H Thermal Magnetic Circuit Breaker

HJA260602

HJA260602 is a 2 pole, 60 amp, 600 volt thermal magnetic molded case circuit breaker from Square D's PowerPact H series with I-Line plug-in mounting.This circuit breaker features a 25kA interrupting rating at 600VAC and 65kA at 480VAC, designed for reliable protection in panelboards and switchboards. It includes long time and instantaneous trip functions, supports wire gauges AWG 14 to 3/0 for aluminum and copper, and is UL, CSA, CE, NEMA, NOM, and IEC certified.

Key Specifications
• Manufacturer: Square D
• Part Number: HJA260602
• Series/Frame: PowerPact H
• Amperage: 60A
• Voltage: 600VAC
• Poles: 2
• Mounting Type: I-Line Style Plug-In
• Interrupt Rating: 25kA at 600VAC, 65kA at 480VAC
• Trip Unit: Thermal Magnetic with Long Time and Instantaneous Trip
• Certifications: UL, CSA, CE, NEMA, NOM, IEC
• Wire Gauge: AWG 14 to AWG 3/0 Aluminum/Copper
• Operating Temperature: -2 to 70 °C

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: HJA260602
• Manufacturer : Schneider Electric
• Brand : Square D
• Category : Circuit Breaker
• Item Subcategory : Molded Case
• Family : Powerpact
• Type : HJA
• Voltage : 600
• Amperage : 60
• Phase : 1
• Poles : 2
• AIC rating : 65kA@480V
• Connection : I-Line Style Plug-In
• Functions : Long Time and Instantaneous Trip
• Frame Size : H Frame
• Temp Rating : -13–158 °F (-25–70 °C)
• Protection : Thermal Magnetic

Product Data

• UPC : 785901795698
• GTIN : 00785901795698
• Country of Origin : Mexico
• Dimensions : 6.4 in (163 mm) x 4.09 in (104 mm) x 3.4 in (86 mm) (Height x Width x Depth)
• Weight : 3.999
• Standards : UL, CSA, NEMA, NOM-003-SCFI-2000, IEC 60947-2
• Certification : UL, CSA, NOM
• Wire Size : AWG 14...AWG 3/0 aluminium/copper terminal
