HGL36150SA - Square D 150A 600V 3-Pole Powerpact H-Frame Molded Case Circuit Breaker

HGL36150SA

HGL36150SA is a Square D Powerpact H-Frame molded case circuit breaker rated for 150 amps and 600 volts with 3 poles.

This thermal-magnetic circuit breaker features a long-time and instantaneous (LI) trip unit, providing reliable protection with a high interrupting capacity of 35kA at 480V. It is designed for unit mount lug installation with feed-thru lugs on both line and load sides, suitable for three-phase applications. The breaker supports AWG 14 to 3/0 aluminum or copper conductors and is UL listed for safety and performance.

• Amperage: 150 A
• Voltage Rating: 600 V AC
• Poles: 3
• Frame Type: H-Frame
• Trip Unit: Thermal-magnetic with Long-Time and Instantaneous (LI) functions
• Interrupt Rating: 35 kA at 480 V AC
• Mounting Type: Unit Mount Lug
• Connection: Feed-Thru Lugs (line and load side)
• Phase: 3
• Control Type: Toggle
• Compatible Wire Gauge: AWG 14 to 3/0 aluminum/copper
• UL Listed

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Additional Information

complete with 110/130Vac shunt trip

Specifications

• Part Number: HGL36150SA
• Manufacturer : Schneider Electric
• Brand : Square D
• Category : Circuit Breaker
• Item Subcategory : Molded Case
• Family : Powerpact
• Type : HGL
• Voltage : 600
• Amperage : 150
• Phase : 3
• Poles : 3
• AIC rating : 35kA@480V
• Connection : Feed-Thru
• Functions : LI - Long-Time and Instantaneous
• Frame Size : H Frame
• Temp Rating : 28-158 °F (-2-70 °C)
• Protection : Thermal Magnetic

Product Data

• UPC : 785901676928
• GTIN : 00785901676928
• Country of Origin : United States
• Dimensions : 6.4 in (163 mm) x 4.09 in (104 mm) x 3.4 in (86 mm) (Height x Width x Depth)
• Weight : 4.2
• Standards : UL, CSA, NEMA, NOM-003-SCFI-2000, IEC 60947-2
• Certification : UL, CSA, NOM
• Wire Size : AWG 14...AWG 3/0 aluminium/copper terminal
