HGL36030AASA - Square D PowerPact H 30A 3 Pole 600V Molded Case Circuit Breaker

Save $3,401.11
SKU: HGL36030AASA-ReCert
Condition: Re-Certified
Price:
$1,810.89 $5,212.00
Stock:
3 in stock
Limited availability — we'll confirm stock immediately after your order.
This ships in 1-2 business days

Same-Day Shipping

Most items ship same-day if ordered by 1:30 PM PST.

2 Year Warranty Guaranteed

All items both Re-Certified, and New sold by Essential Electric include a 30 day return policy and a 2-year full warranty. This means that they are guaranteed to be free from defects for a full 2 years from the date that the product was shipped from our warehouse.

Product Questions? Contact Us

Product Info

HGL36030AASA - Square D Feed-Thru 600V 30A 3 pole circuit breaker 35kA@480V - Essential Electric Supply
Roll over image to zoom in Click on image to zoom Images are for reference only
HGL36030AASA - Square D Feed-Thru 600V 30A 3 pole circuit breaker 35kA@480V - Essential Electric Supply

Description

HGL36030AASA


HGL36030AASA is a Square D PowerPact H series molded case circuit breaker designed for reliable protection in commercial and industrial applications. This 30A, 3 pole breaker features a thermal magnetic trip unit and is rated for up to 600V AC, making it suitable for a wide range of electrical systems. The unit mount design allows for easy installation and integration into various panel configurations. Compliant with UL 489, CSA, and IEC standards, this breaker ensures safety and performance in demanding environments. The HGL36030AASA offers a robust interrupting rating of 18kA at 600VAC, providing dependable protection against short circuits and overloads. Its compact size and versatile mounting options make it ideal for retrofitting or new installations. The breaker is constructed with high-quality materials for long-term durability and consistent operation.
  • Part Number: HGL36030AASA
  • Manufacturer: Square D
  • Series/Frame: PowerPact H
  • Amperage: 30A
  • Poles: 3
  • Voltage Rating: 600V AC
  • Mounting Type: Unit Mount
  • Interrupt Rating: 18kA @ 600VAC
  • Trip Unit: Thermal Magnetic
  • Certifications: UL 489, CSA, IEC
  • Frame Type: H
  • Application: Commercial, Industrial
At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Additional Information

complete with 1A/1B auxiliary switch and 110/130Vac shunt trip


Specifications

  • Part Number: HGL36030AASA
  • Manufacturer : Schneider Electric
  • Brand : Square D
  • Category : Circuit Breaker
  • Item Subcategory : Molded Case
  • Voltage : 600
  • Amperage : 30
  • Phase : 3
  • Poles : 3
  • AIC rating : 35kA@480V
  • Connection : Feed-Thru
  • Functions : LI - Long-Time and Instantaneous
  • Temp Rating : 28-158 °F (-2-70 °C)
  • Protection : Thermal Magnetic

Product Data

  • UPC : 785901054160
  • Dimensions : 6.4 in (163 mm) x 4.09 in (104 mm) x 3.4 in (86 mm) (Height x Width x Depth)
  • Weight : 5
  • Standards : UL, CSA, NEMA, NOM-003-SCFI-2000, IEC 60947-2
  • Certification : UL, CSA, NOM
  • Wire Size : AWG 14...AWG 3/0 aluminium/copper terminal

Accesories

Part Manufacture Sub Category
S29450
S29386
S29412
