HGL26025 - Square D PowerPact H Frame 25 Amp 2 Pole Molded Case Circuit Breaker 600VAC Unit Mount

HGL26025

HGL26025 is a Square D PowerPact H Frame 25 Amp 2 Pole Molded Case Circuit Breaker designed for reliable protection in commercial and industrial applications. This unit mount breaker features a thermal magnetic trip unit and is UL 489 listed for safety and compliance. Engineered for durability and performance, the HGL26025 offers high interrupting capacity with ratings up to 65kA at 240VAC, 35kA at 480VAC, and 18kA at 600VAC. It is suitable for reverse fed applications and includes line and load side lug terminals for easy installation.

• Part Number: HGL26025
• Manufacturer: Square D
• Series/Frame: PowerPact H Frame
• Amperage: 25 Amp
• Number of Poles: 2
• Maximum Voltage: 600VAC
• Mounting Type: Unit Mount
• Interrupt Rating: 65kA @ 240VAC, 35kA @ 480VAC, 18kA @ 600VAC
• Trip Unit: Thermal Magnetic
• Certifications: UL 489 Listed
• Application: Commercial and Industrial
• Terminal Type: Line and Load Side Lug

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: HGL26025
• Manufacturer : Schneider Electric
• Brand : Square D
• Category : Circuit Breaker
• Item Subcategory : Molded Case
• Family : Powerpact
• Type : HGL
• Voltage : 600
• Amperage : 25
• Phase : 1
• Poles : 2
• AIC rating : 35kA@480V
• Connection : Bolt-On
• Functions : Long Time and Instantaneous
• Terminal Connection : Line/Load Lug
• Frame Size : 150A/HG
• Temp Rating : -13–158 °F (-25–70 °C)
• MCM Size : Min. Wire Size 14 AWG Max. Wire Size 3 AWG
• Breaker Type : Standard
• Protection : Thermal Magnetic
• Phase Connection : Not Applicable

Product Data

• UPC : 785901433774
• GTIN : 00785901433774
• Country of Origin : United States
• Dimensions : 6.4 in (163 mm) x 4.09 in (104 mm) x 3.4 in (86 mm) (Height x Width x Depth)
• Weight : 3.001
• Standards : UL, CSA, NEMA, NOM-003-SCFI-2000, IEC 60947-2
• Certification : UL, CSA, NOM
• Wire Size : AWG 14...AWG 3/0 aluminium/copper terminal
