HGA36150U44X - Schneider Electric 150A 3-Pole 600V PowerPact HGA Circuit Breaker I-Line Plug-In 35kA@480V LSIG Trip

HGA36150U44X

HGA36150U44X is a Schneider Electric 150 amp, 3-pole, 600 Volt PowerPact HGA molded case circuit breaker with I-Line style plug-in mounting and a 35kA interrupting rating at 480V.This circuit breaker features solid state electronic trip units with LSIG (Long-Time, Short-Time, Instantaneous, and Ground Fault) protection functions. It is UL listed and suitable for ABC phase connection with a non-interchangeable Micrologic 6.2A trip unit. The breaker supports high interrupting capacity and is designed for reliable protection in commercial and industrial power distribution.

• Amperage: 150A
• Voltage Rating: 600V AC
• Poles: 3
• Mounting Type: I-Line Style Plug-In
• Interrupt Rating: 35kA at 480V
• Series/Frame: PowerPact HGA
• Trip Unit: Micrologic 6.2A, LSIG (Long-Time, Short-Time, Instantaneous, Ground Fault)
• Phase: 3 (ABC connection)
• UL Listed
• Solid State Electronic Trip
• Suitable for Reverse Connection
• Weight: Approximately 4.85 lbs

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: HGA36150U44X
• Manufacturer : Schneider Electric
• Brand : Schneider Electric
• Category : Circuit Breaker
• Item Subcategory : Molded Case
• Family : Powerpact
• Type : HGA
• Voltage : 600
• Amperage : 150
• Phase : 3
• Poles : 3
• AIC rating : 35kA@480V
• Connection : I-Line Style Plug-In
• Functions : LSIG - Long-Time, Short-Time, Instantaneous and Ground Fault
• Terminal Connection : I-Line, Lug
• Frame Size : H
• Temp Rating : 28-158 °F (-2-70 °C)
• MCM Size : Min. Wire Size 14 AWG (Cu/Al) Max. Wire Size 3/0 AWG (Cu/Al)
• Protection : Solid State
• Phase Connection : ABC

Product Data

• UPC : 785901612650
• GTIN : 00785901612650
• Country of Origin : United States
• Dimensions : 6.4 in (163 mm) x 4.09 in (104 mm) x 3.4 in (86 mm) (Height x Width x Depth)
• Weight : 8.001
• Standards : UL, CSA, NEMA, NOM-003-SCFI-2000, IEC 60947-2
• Certification : UL, CSA, NOM
• Wire Size : AWG 14...AWG 3/0 aluminium/copper terminal
