HGA36060U43X - Schneider Electric PowerPact H-Frame 60A 3 Pole 600V I-Line Plug-In Circuit Breaker

HGA36060U43X

HGA36060U43X is a Schneider Electric PowerPact H-Frame molded case circuit breaker designed for reliable protection in industrial and commercial power distribution systems. This breaker features a 60A current rating, 3 poles, and is rated for 600V AC, making it suitable for a wide range of applications. It utilizes an I-Line style plug-in mounting for easy installation and replacement. The HGA36060U43X is equipped with a Micrologic 5.2A trip unit, providing advanced protection and monitoring capabilities. Its LSI trip function and 18kA interrupt rating ensure robust performance under fault conditions. This breaker is part of the PowerPact H series, known for durability and high performance in demanding environments.

• 60A current rating
• 3 poles
• 600V AC voltage rating
• I-Line style plug-in mounting
• 18kA interrupt rating at 600V AC
• PowerPact H-Frame series
• Micrologic 5.2A trip unit
• LSI trip function
• ABC main configuration
• 80% frame rating
• Compatible with I-Line bus systems
• Designed for industrial and commercial use

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: HGA36060U43X
• Manufacturer : Schneider Electric
• Brand : Schneider Electric
• Category : Circuit Breaker
• Item Subcategory : Molded Case
• Family : Powerpact
• Type : HGA
• Voltage : 600
• Amperage : 60
• Phase : 3
• Poles : 3
• AIC rating : 35kA@480V
• Connection : I-Line Style Plug-In
• Functions : LSI - Long-Time, Short-Time and Instantaneous
• Terminal Connection : I-Line, Lug
• Frame Size : H
• Temp Rating : 28-158 °F (-2-70 °C)
• MCM Size : Min. Wire Size 14 AWG (Cu/Al) Max. Wire Size 3/0 AWG (Cu/Al)
• Protection : Solid State
• Phase Connection : ABC

Product Data

• UPC : 060648628246
• GTIN : 03606486282465
• Country of Origin : Mexico
• Dimensions : 6.4 in (163 mm) x 4.09 in (104 mm) x 3.4 in (86 mm) (Height x Width x Depth)
• Weight : 8.001
• Standards : UL, CSA, NEMA, NOM-003-SCFI-2000, IEC 60947-2
• Certification : UL, CSA, NOM
• Wire Size : AWG 14...AWG 3/0 aluminium/copper terminal
