HFDE308033L - Eaton 80A 600VAC 3-Pole Series C Electronic Molded Case Circuit Breaker

HFDE308033L

HFDE308033L is an Eaton Series C electronic molded case circuit breaker designed for industrial and commercial power distribution applications requiring reliable overcurrent protection.

This F-frame HFD series breaker features a solid state electronic trip unit (Digitrip 310 RMS) with long-time and short-time trip functions. The breaker is rated for 80 amperes at 600 VAC (250 VDC) with three-pole configuration, making it suitable for three-phase systems. It includes line and load side lug terminals for flexible installation and operates at 50/60 Hz. The patented contact design delivers high-speed blow-open action for superior performance and arc suppression.

• Amperage Rating: 80 A
• Voltage Rating: 600 VAC / 250 VDC
• Poles: 3 (Three-Pole)
• Frame Type: F-Frame (HFD Series)
• Trip Unit: Electronic LS (Digitrip 310 RMS)
• Interrupt Rating: 100 kAIC @ 240V, 65 kAIC @ 480V
• Terminal Type: Line and Load Side Lug Terminals
• Frequency: 50/60 Hz
• Country of Origin: US
• Weight: 2.025 kg

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: HFDE308033L
• Manufacturer : Eaton
• Brand : Cutler Hammer
• Category : Circuit Breaker
• Item Subcategory : Molded Case
• Family : Series C
• Type : HFDE
• Voltage : 480 AC
• Amperage : 80
• Phase : 3
• Poles : 3
• AIC rating : 65kA@480V
• Connection : Feed-Thru
• Functions : Long Time and Short Time Trip Functions
• Frame Size : F Frame
• Protection : Solid State

Product Data

• UPC : 786685112459
• GTIN : 00786685112459
• Country of Origin : Dominican Republic
• Dimensions : 3.38 in x 6 in x 4.13 in (Length/Depth x Height x Width)
• Weight : 4.5
• Certification : UL Listed
