Product Info
- Manufacturer:Eaton
- Sub-Category:Molded Case
Description
HFD4050
HFD4050 - Eaton Series C F-frame molded case circuit breaker with fixed thermal-magnetic trip, rated at 50A, 600VAC, four-pole.
This complete HFD breaker features fixed thermal-fixed magnetic trip type, 100 kAIC at 240VAC and 65 kAIC at 480VAC interrupting ratings, 50/60 Hz frequency, and 250 VDC capability. It utilizes patented high-speed blow-open contact design for superior arc interruption performance in panel or surface mounting applications.
Key Specifications
- Amperage Rating: 50A
- Voltage Rating: 600VAC / 250VDC
- Poles: 4
- Frame: F-Frame
- Series: C Series
- Trip Unit: Fixed Thermal-Magnetic
- Interrupt Rating: 100 kAIC @ 240VAC, 65 kAIC @ 480VAC
- Frequency: 50/60 Hz
- Mounting Type: Panel / Surface
- Connection: Bolt-On
At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.
Specifications
- Part Number: HFD4050
- Manufacturer : Eaton
- Category : Circuit Breaker
- Item Subcategory : Molded Case
- Family : Series C
- Type : HFD
- Voltage : 600 AC
- Amperage : 50
- Phase : 3
- Poles : 4
- AIC rating : 65kA@480V
- Connection : Bolt-On
- Functions : LI - Long-Time and Instantaneous
- Frame Size : F Frame
- Protection : Thermal Magnetic
Product Data
- UPC : 786679253854
- GTIN : 00786679253854
- Country of Origin : Dominican Republic
- Dimensions : 3.38 in x 6 in x 5.5 in (Length/Depth x Height x Width)
- Weight : 4.5
- Certification : UL Listed
