Product Info
- Manufacturer:Eaton
- Sub-Category:Molded Case
Description
HFD4040L
HFD4040L is a four-pole, 40 amp molded case circuit breaker from Eaton's Series C line, designed for reliable protection in commercial and industrial power distribution systems.This Eaton Series C circuit breaker features a 40 amp continuous current rating, supports up to 600 Vac and 250 Vdc, and is suitable for both line and load connections. The HFD4040L is built with a robust F-frame construction and is engineered for durability and safety in demanding electrical environments.
- 40 Amp continuous current rating
- 600 Vac maximum voltage
- 250 Vdc maximum voltage
- Four-pole configuration
- Series C, F-frame design
- Thermal-magnetic trip unit
- Line and load terminals
- 100 kA interrupt rating at 240 Vac
- 65 kA interrupt rating at 480 Vac
- 25 kA interrupt rating at 600 Vac
- UL/CSA certified
Specifications
- Part Number: HFD4040L
- Manufacturer : Eaton
- Brand : Cutler Hammer
- Category : Circuit Breaker
- Item Subcategory : Molded Case
- Family : Series C
- Type : HFD
- Voltage : 600 AC
- Amperage : 40
- Phase : 3
- Poles : 4
- AIC rating : 65kA@480V
- Connection : Feed-Thru
- Functions : LI - Long-Time and Instantaneous
- Frame Size : F Frame
- Protection : Thermal Magnetic
Product Data
- UPC : 786679271353
- GTIN : 00786679271353
- Country of Origin : Dominican Republic
- Dimensions : 3.38 in x 6 in x 5.5 in (Length/Depth x Height x Width)
- Weight : 4.5
- Certification : UL Listed
