HFD4020L - Eaton 20A 600VAC 250VDC 4-Pole Molded Case Circuit Breaker F-Frame Fixed Thermal Magnetic Trip

HFD4020L

HFD4020L is a Eaton Series C complete molded case circuit breaker with a 20 amp rating and four poles.This breaker features a fixed thermal and fixed magnetic trip unit, designed for panel mounting. It supports a maximum voltage of 600 VAC and 250 VDC, with interrupt ratings of 100 kAIC at 240 VAC and 65 kAIC at 480 VAC. The breaker is part of Eaton's F-frame HFD series and is UL listed for safety and reliability.

• Amperage: 20 A
• Voltage: 600 VAC, 250 VDC
• Poles: 4
• Trip Unit: Fixed Thermal / Fixed Magnetic
• Mounting Type: Panel
• Interrupt Rating: 100 kAIC at 240 VAC, 65 kAIC at 480 VAC
• Series/Frame: Eaton Series C, F-frame
• Certifications: UL Listed
• Weight: 4.5 lbs
• Dimensions: 6 in H x 5.5 in W x 3.38 in D

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: HFD4020L
• Manufacturer : Eaton
• Brand : Cutler Hammer
• Category : Circuit Breaker
• Item Subcategory : Molded Case
• Family : Series C
• Type : HFD
• Voltage : 600 AC
• Amperage : 20
• Phase : 3
• Poles : 4
• AIC rating : 65kA@480V
• Connection : Feed-Thru
• Functions : LI - Long-Time and Instantaneous
• Frame Size : F Frame
• Protection : Thermal Magnetic

Product Data

• UPC : 786679271315
• GTIN : 00786679271315
• Country of Origin : Dominican Republic
• Dimensions : 3.38 in x 6 in x 5.5 in (Length/Depth x Height x Width)
• Weight : 4.5
• Certification : UL Listed
