Product Info
- Manufacturer:Eaton
- Sub-Category:Molded Case
Description
HFD3175LBP10
HFD3175LBP10 is a 175 amp, 600 volt, 3-pole molded case circuit breaker from Eaton's Series C F-frame line.This Eaton HFD3175LBP10 circuit breaker features a fixed thermal-magnetic trip unit designed for reliable protection in three-phase electrical systems. It has a bolt-on connection type and is rated for 65kA interrupting capacity at 480V AC and 100kA at 240V AC. The breaker is UL Listed and suitable for use in industrial and commercial applications requiring high interrupting capacity and robust performance.
- Amperage: 175 A
- Voltage Rating: 600 Vac, 250 Vdc
- Poles: 3
- Frame Type: F-Frame (Series C)
- Trip Unit: Fixed Thermal Magnetic
- Interrupt Rating: 65 kAIC at 480 Vac, 100 kAIC at 240 Vac
- Connection Type: Bolt-On
- Phase: 3
- Certifications: UL Listed
Specifications
- Part Number: HFD3175LBP10
- Manufacturer : Eaton
- Brand : Cutler Hammer
- Category : Circuit Breaker
- Item Subcategory : Molded Case
- Family : Series C
- Type : HFD
- Voltage : 600 AC
- Amperage : 175
- Phase : 3
- Poles : 3
- AIC rating : 65kA@480V
- Connection : Feed-Thru
- Functions : LI - Long-Time and Instantaneous
- Frame Size : F Frame
- Protection : Thermal Magnetic
Product Data
- Weight : 4
