Product Info
- Manufacturer:Westinghouse
- Sub-Category:Molded Case
Description
HFD3080VL
HFD3080VL is a Westinghouse Series C 80 Amp 600 Volt 3-Pole Molded Case Circuit Breaker designed for industrial applications.This circuit breaker features a thermal-magnetic trip unit providing reliable protection against overloads and short circuits. It supports a voltage rating up to 600 VAC and 250 VDC, with an interrupt rating of 65 kA at 480 VAC and 100 kA at 240 VAC. The breaker is built on the F-frame Series C platform, suitable for heavy-duty use with a 3-pole configuration.
- Amperage: 80A
- Voltage: 600 VAC, 250 VDC
- Poles: 3
- Series/Frame: Series C, F-Frame
- Trip Unit: Thermal Magnetic
- Interrupt Rating: 65 kA at 480 VAC, 100 kA at 240 VAC
- Mounting Type: Molded Case
- Frequency: 50/60 Hz
- Operating Temperature: 40¡C
Specifications
- Part Number: HFD3080VL
- Manufacturer : Westinghouse
- Brand : Westinghouse
- Category : Circuit Breaker
- Item Subcategory : Molded Case
- Family : Series C
- Type : HFD
- Voltage : 600 AC
- Amperage : 80
- Phase : 3
- Poles : 3
- AIC rating : 65kA@480V
- Connection : Feed-Thru
- Functions : LI - Long-Time and Instantaneous
- Protection : Thermal Magnetic
Product Data
- UPC : 786679396605
- GTIN : 00786679396605
- Country of Origin : Dominican Republic
- Dimensions : 3.38 in x 6 in x 4.13 in (Length/Depth x Height x Width)
- Weight : 4.5
- Certification : UL Listed
