Product Info
- Manufacturer:Eaton
- Sub-Category:Molded Case
Description
HFD3015BP10
HFD3015BP10 is a 15 Amp, 3-Pole Series C NEMA F-Frame molded case circuit breaker from Eaton with fixed thermal-magnetic trip protection, rated for 600 VAC and 250 VDC operation. This Type HFD breaker features cable in/cable out configuration and delivers 65 kAIC interrupt rating at 480 VAC and 100 kAIC at 240 VAC, making it suitable for industrial and commercial power distribution applications. The breaker includes load terminals only and must be ordered in quantities of 10.
- Manufacturer: Eaton
- Part Number: HFD3015BP10
- Amperage: 15 A
- Poles: 3
- Voltage Rating: 600 VAC / 250 VDC
- Series: C
- Frame: F-Frame
- Type: HFD
- Trip Unit: Fixed Thermal-Magnetic
- Interrupt Rating: 65 kAIC at 480 VAC / 100 kAIC at 240 VAC
- Mounting: Panel
- Configuration: Cable In/Cable Out
Specifications
- Part Number: HFD3015BP10
- Manufacturer : Eaton
- Brand : Cutler Hammer
- Category : Circuit Breaker
- Item Subcategory : Molded Case
- Family : Series C
- Type : HFD
- Voltage : 600 AC
- Amperage : 15
- Phase : 3
- Poles : 3
- AIC rating : 65kA@480V
- Connection : Bolt-On
- Functions : LI - Long-Time and Instantaneous
- Protection : Thermal Magnetic
Product Data
- UPC : 786685020938
- GTIN : 00786685020938
- Country of Origin : Dominican Republic
- Dimensions : 3.38 in x 5.9 in x 4.1 in (Length/Depth x Height x Width)
- Weight : 3.75
- Certification : UL Listed
