Product Info
- Manufacturer:Eaton
- Sub-Category:Molded Case
Description
HFD3060BP10
HFD3060BP10 - Eaton Series C F-frame molded case circuit breaker with fixed thermal-magnetic trip, rated at 60A, three-pole, 600VAC/250VDC.This HFD type breaker features cable in/cable out connections, panel mounting, and high interrupt ratings including 100kAIC at 240VAC and 65kAIC at 480VAC. It includes load terminals and operates at 50/60Hz with patented contact design for superior performance in demanding applications.
- Part Number: HFD3060BP10
- Manufacturer: Eaton
- Amperage: 60A
- Poles: 3
- Voltage AC: 600V
- Voltage DC: 250V
- Frame: F-frame, Series C
- Trip Type: Fixed thermal-magnetic
- Interrupt Rating: 100kAIC@240VAC, 65kAIC@480VAC
- Mounting: Panel
Specifications
- Part Number: HFD3060BP10
- Manufacturer : Eaton
- Brand : Cutler Hammer
- Category : Circuit Breaker
- Item Subcategory : Molded Case
- Family : Series C
- Type : HFD
- Voltage : 600 AC
- Amperage : 60
- Phase : 3
- Poles : 3
- AIC rating : 65kA@480V
- Connection : Bolt-On
- Functions : LI - Long-Time and Instantaneous
- Frame Size : F Frame
- Protection : Thermal Magnetic
Product Data
- UPC : 786685021003
- GTIN : 00786685021003
- Country of Origin : Dominican Republic
- Dimensions : 3.38 in x 6 in x 4.13 in (Length/Depth x Height x Width)
- Weight : 42.4
- Certification : UL Listed
