Product Info
- Manufacturer:Eaton
- Sub-Category:Molded Case
Description
HFD1080L
HFD1080L is an Eaton Series C complete molded case circuit breaker designed for reliable power distribution and circuit protection in industrial and commercial applications. This single-pole breaker features fixed thermal and fixed magnetic trip technology with line and load terminals, delivering consistent performance across 50/60 Hz systems. The F-frame design provides a compact footprint while maintaining robust interrupt capacity for demanding environments.
- Amperage Rating: 80 Amp
- Voltage Rating: 347 Vac, 125 Vdc
- Poles: Single Pole (1P)
- Frame Type: F-Frame
- Series: Series C
- Trip Type: Fixed Thermal, Fixed Magnetic
- Interrupt Rating: 100 kAIC at 240V, 65 kAIC at 480V
- Terminals: Line and Load
- Frequency: 50/60 Hz
- Circuit Breaker Type: HFD Complete Breaker
Specifications
- Part Number: HFD1080L
- Manufacturer : Eaton
- Brand : Cutler Hammer
- Category : Circuit Breaker
- Item Subcategory : Molded Case
- Family : Series C
- Type : HFD
- Voltage : 277 AC
- Amperage : 80
- Phase : 1
- Poles : 1
- AIC rating : 65kA@277V
- Connection : Feed-Thru
- Functions : LI - Long-Time and Instantaneous
- Frame Size : F Frame
- Protection : Thermal Magnetic
Product Data
- UPC : 078667924768
- GTIN : 00786679247686
- Country of Origin : Dominican Republic
- Dimensions : 3.38 in x 6 in x 1.38 in (Length/Depth x Height x Width)
- Weight : 4.5
- Certification : UL Listed
