Product Info
- Manufacturer:Eaton
- Sub-Category:Molded Case
Description
HFD1015BP10
HFD1015BP10 is a single-pole molded case circuit breaker from Eaton's Series C line, rated for 15 amperes at 347 volts AC and 125 volts DC with fixed thermal and magnetic trip protection. This load-side terminal breaker is designed for industrial and commercial power distribution applications requiring reliable overcurrent protection in 50/60 Hz systems. The HFD series delivers consistent performance with high interrupt ratings suitable for demanding electrical environments.
- Amperage: 15A
- Voltage: 347 Vac, 125 Vdc
- Number of Poles: 1-Pole
- Type: Molded Case Circuit Breaker
- Series: Eaton Series C
- Trip Unit: Fixed Thermal and Fixed Magnetic
- Interrupt Rating: 65 kAIC at 277 Vac, 25 kAIC at 600 Vac
- Frequency: 50/60 Hz
- Terminal Type: Load Side
Specifications
- Part Number: HFD1015BP10
- Manufacturer : Eaton
- Brand : Cutler Hammer
- Category : Circuit Breaker
- Item Subcategory : Molded Case
- Family : Series C
- Type : HFD
- Voltage : 277 AC
- Amperage : 15
- Phase : 1
- Poles : 1
- AIC rating : 65kA@277V
- Connection : Bolt-On
- Functions : LI - Long-Time and Instantaneous
- Frame Size : F Frame
- Protection : Thermal Magnetic
Product Data
- UPC : 786679048290
- GTIN : 00786679048290
- Country of Origin : Dominican Republic
- Dimensions : 3.38 in x 4.1 in x 1.38 in (Length/Depth x Height x Width)
- Weight : 1.45
- Certification : UL Listed
