HF365NRA - Siemens 400A 600V 3P Fused Heavy Duty Safety Switch NEMA 3R Outdoor Surface Mount

HF365NRA

HF365NRA is a Siemens heavy duty fused safety switch rated for 400 amps and 600 volts AC with 3 poles and neutral, designed for outdoor use.This Siemens HF365NRA safety switch features a 3-pole, 4-wire configuration with a 200kA interrupting rating, Type 3R NEMA enclosure for outdoor surface mounting, and lever-operated actuator. It supports up to 125 hp motor rating at 600 VAC and is UL and CSA listed for reliable low voltage circuit protection.

Key Specifications
• Amperage: 400 A
• Voltage: 600 VAC
• Poles: 3
• Wires: 4 (including neutral)
• Interrupt Rating: 200 kAIC
• Mounting Type: Surface Mount
• Enclosure: NEMA 3R Outdoor
• Trip Unit: Fused
• Horsepower Rating: 125 hp at 600 VAC
• Standards: UL Listed, CSA Listed
• Operating Temperature: -20 to 120 ÁF

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: HF365NRA
• Manufacturer : Siemens
• Brand : Siemens
• Category : Switch
• Item Subcategory : Disconnect
• Section : Fusible Disconnect Switch
• Family : VBII Series
• Type : HF
• Voltage : 600 AC AC
• Amperage : 400
• Phase : 3
• Poles : 3
• AIC rating : 200kA@600V
• Temp Rating : -13ÁF - 158ÁF (-25ÁC - 70ÁC)
• Fuse Class : R
• Configuration : Single
• Switch Style : Fusible
• Nema Rating : NEMA 3R
• Compatible Frames : PGP

Product Data

• UPC : 887621872434
• GTIN : 00887621872434
• Country of Origin : Mexico
• Dimensions : 6.693 x 22.047 x 45.276 inch
• Weight : 94.583 lb
• Temp Rating : -13ÁF - 158ÁF (-25ÁC - 70ÁC)
• Certification : UL listed
