HDL36110SA - Square D 110A 3-Pole 600V Thermal-Magnetic PowerPact H Circuit Breaker

HDL36110SA

HDL36110SA is a Square D PowerPact H series 3-pole circuit breaker rated for 110 amps and 600 volts with a thermal-magnetic trip unit.

This molded case circuit breaker features a unit mount design with lug-type electrical connections suitable for both line and load. It offers interrupt ratings of 25 kA at 240 VAC, 18 kA at 480 VAC, 14 kA at 600 VAC, and 20 kA at 250 VDC, providing robust protection for electrical circuits. The breaker complies with IEC, CSA, CE, and UL certifications and operates reliably up to 104°F (40°C) ambient temperature.

• Amperage: 110 A
• Voltage Rating: 600 V AC, 250 V DC
• Number of Poles: 3
• Trip Unit Type: Thermal-Magnetic
• Interrupt Rating: 25 kA @ 240 V AC, 18 kA @ 480 V AC, 14 kA @ 600 V AC, 20 kA @ 250 V DC
• Mounting Type: Unit Mount
• Electrical Connection: Lug load and line
• Series/Frame: PowerPact H
• Certifications: IEC, CSA, CE, UL Listed
• Ambient Operating Temperature: 104°F (40°C)

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Additional Information

complete with 100/130Vac shunt trip

Specifications

• Part Number: HDL36110SA
• Manufacturer : Schneider Electric
• Brand : Square D
• Category : Circuit Breaker
• Item Subcategory : Molded Case
• Family : Powerpact
• Type : HDL
• Voltage : 600
• Amperage : 110
• Phase : 3
• Poles : 3
• AIC rating : 18kA@480V
• Connection : Feed-Thru
• Functions : LI - Long-Time and Instantaneous
• Frame Size : H Frame
• Temp Rating : 28-158 °F (-2-70 °C)
• Protection : Thermal Magnetic

Product Data

• UPC : 785901911241
• GTIN : 00785901911241
• Country of Origin : United States
• Dimensions : 6.4 in (163 mm) x 4.09 in (104 mm) x 3.4 in (86 mm) (Height x Width x Depth)
• Weight : 5
• Standards : UL, CSA, NEMA, NOM-003-SCFI-2000, IEC 60947-2
• Certification : UL, CSA, NOM
• Wire Size : AWG 14...AWG 3/0 aluminium/copper terminal
