HDL36100U43X - Square D 100 Amp 600 Volt 3-Pole PowerPact H Molded Case Circuit Breaker

HDL36100U43X

HDL36100U43X is a Square D PowerPact H molded case circuit breaker designed for reliable protection of electrical systems. This 3-pole breaker provides 100 amps of trip current capacity and operates at up to 600 volts. It features an electronic trip unit with Micrologic 5.2 technology, offering advanced protection including long-time, short-time, and instantaneous trip functions with current limiting capability. The breaker is built to PowerPact H frame specifications and is suitable for three-phase applications.

• Manufacturer: Square D
• Part Number: HDL36100U43X
• Amperage: 100 Amps trip rating
• Voltage Rating: 600 Volts AC
• Poles: 3
• Frame: PowerPact H
• Trip Unit: Electronic Micrologic 5.2 with LSI (Long-time, Short-time, Instantaneous)
• Interrupt Rating: 25 kA
• Phase: 3-phase

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: HDL36100U43X
• Manufacturer : Schneider Electric
• Brand : Square D
• Category : Circuit Breaker
• Item Subcategory : Molded Case
• Family : Powerpact
• Type : HDL
• Voltage : 600
• Amperage : 100
• Phase : 3
• Poles : 3
• AIC rating : 18kA@480V
• Connection : Feed-Thru
• Functions : LSI - Long-Time, Short-Time and Instantaneous
• Terminal Connection : Lug
• Frame Size : H
• Temp Rating : 28-158 °F (-2-70 °C)
• MCM Size : Min. Wire Size 14 AWG (Cu/Al) Max. Wire Size 3/0 AWG (Cu/Al)
• Protection : Solid State

Product Data

• UPC : 060648628214
• GTIN : 03606486282144
• Country of Origin : Mexico
• Dimensions : 6.4 in (163 mm) x 4.09 in (104 mm) x 3.4 in (86 mm) (Height x Width x Depth)
• Weight : 5
• Standards : UL, CSA, NEMA, NOM-003-SCFI-2000, IEC 60947-2
• Certification : UL, CSA, NOM
• Wire Size : AWG 14...AWG 3/0 aluminium/copper terminal
