HDL36060SA - Square D 60A 600V 3-Pole H-Frame Molded Case Circuit Breaker, Thermal Magnetic Trip, 18kA@480VAC, 25kA@240VAC, 14kA@600VAC, 20kA@250VDC, UL 489 Listed, NEMA AB1 Enclosure

HDL36060SA

HDL36060SA is a Square D 60A, 600V, 3-pole molded case circuit breaker designed for reliable circuit protection in industrial and commercial applications.

This thermal magnetic, current-limiting circuit breaker features an H-frame design, unit mounting, and is UL 489 listed for safety and compliance. It offers high interrupt ratings across multiple voltages, making it suitable for a wide range of electrical distribution needs.

Key Specifications
• Part Number: HDL36060SA
• Manufacturer: Square D
• Amperage: 60A
• Voltage: 600V AC, 250V DC
• Poles: 3
• Mounting Type: Unit Mount
• Interrupt Rating: 18kA @ 480VAC, 25kA @ 240VAC, 14kA @ 600VAC, 20kA @ 250VDC
• Series/Frame: H-Frame (PowerPact H)
• Trip Unit: Thermal Magnetic, Current Limiting
• Certifications: UL 489 Listed
• Enclosure Type: NEMA AB1
• Dimensions: 4.36" L x 4.12" W x 6.4" H

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Additional Information

complete with 110/130Vac shunt trip

Specifications

• Part Number: HDL36060SA
• Manufacturer : Schneider Electric
• Brand : Square D
• Category : Circuit Breaker
• Item Subcategory : Molded Case
• Family : Powerpact
• Type : HDL
• Voltage : 600
• Amperage : 60
• Phase : 3
• Poles : 3
• AIC rating : 18kA@480V
• Connection : Feed-Thru
• Functions : LI - Long-Time and Instantaneous
• Terminal Connection : Lug
• Frame Size : H
• Temp Rating : 28-158 °F (-2-70 °C)
• MCM Size : Min. Wire Size 14 AWG (Cu/Al) Max. Wire Size 3/0 AWG (Cu/Al)
• Protection : Thermal Magnetic

Product Data

• UPC : 785901590972
• GTIN : 00785901590972
• Country of Origin : Mexico
• Dimensions : 6.4 in (163 mm) x 4.09 in (104 mm) x 3.4 in (86 mm) (Height x Width x Depth)
• Weight : 5
• Standards : UL, CSA, NEMA, NOM-003-SCFI-2000, IEC 60947-2
• Certification : UL, CSA, NOM
• Wire Size : AWG 14...AWG 3/0 aluminium/copper terminal
