HDL36060AA - Square D PowerPacT H 60 Amp 3 Pole 600VAC Circuit Breaker

HDL36060AA

HDL36060AA is a PowerPacT H series molded case circuit breaker designed for industrial and commercial power distribution applications.

This thermal magnetic, current limiting circuit breaker features a 60 amp rating at 600 volts AC maximum, with a 14 kA interrupt rating at 600 volts. The unit mount configuration includes lugs on both line and load sides for flexible installation. Operating temperature range is -25 to 70 degrees Celsius, and the breaker weighs 1.81 kilograms. UL 489 listed for safety compliance.

• Amperage: 60 Amp
• Poles: 3 Pole
• Voltage Rating: 600 VAC maximum, 250 VDC maximum
• Interrupt Rating: 14 kA at 600 Volt, 18 kA at 480 Volt, 25 kA at 240 Volt
• Frame Type: H Frame
• Trip Unit: Thermal Magnetic
• Mounting: Unit Mount with Line and Load Lugs
• Series: PowerPacT H
• Certification: UL 489
• Dimensions: 4.12 inches width x 4.36 inches depth x 6.4 inches height
• Weight: 1.81 kilograms
• Operating Temperature: -25 to 70 degrees Celsius

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: HDL36060AA
• Manufacturer : Schneider Electric
• Brand : Square D
• Category : Circuit Breaker
• Item Subcategory : Molded Case
• Family : Powerpact
• Type : HDL
• Voltage : 600
• Amperage : 60
• Phase : 3
• Poles : 3
• AIC rating : 18kA@480V
• Connection : Feed-Thru
• Functions : LI - Long-Time and Instantaneous
• Frame Size : H Frame
• Protection : Thermal Magnetic

Product Data

• UPC : 785901474043
• GTIN : 00785901474043
• Country of Origin : United States
• Dimensions : 6.4 in (163 mm) x 4.09 in (104 mm) x 3.4 in (86 mm) (Height x Width x Depth)
• Weight : 4.9
• Standards : UL, CSA, NEMA, NOM-003-SCFI-2000, IEC 60947-2
• Certification : UL, CSA, NOM
• Wire Size : AWG 14...AWG 3/0 aluminium/copper terminal
