HDL26035 - Square D PowerPact H Frame 35 Amp 2 Pole Molded Case Circuit Breaker 600VAC 14kA Interrupt Rating

Save $374.09
SKU: HDL26035-New
Condition: New
Price:
$495.91 $870.00
Stock:
Low inventory, please call for stock check

Same-Day Shipping

Most items ship same-day if ordered by 12:30 PM PST.

2 Year Warranty Guaranteed

All items both Re-Certified, and New sold by Essential Electric include a 30 day return policy and a 2-year full warranty. This means that they are guaranteed to be free from defects for a full 2 years from the date that the product was shipped from our warehouse.

Product Questions? Contact Us

Product Info

HDL26035 - Schneider Electric/ Square D Feed-Thru 35 Amp 2 Pole Circuit Breaker - Essential Electric Supply
HDL26035 - Square D Bolt-On 600V 35A 2 pole circuit breaker 18kA@480V - Essential Electric Supply
Roll over image to zoom in Click on image to zoom Images are for reference only
HDL26035 - Schneider Electric/ Square D Feed-Thru 35 Amp 2 Pole Circuit Breaker - Essential Electric Supply
HDL26035 - Square D Bolt-On 600V 35A 2 pole circuit breaker 18kA@480V - Essential Electric Supply

Description

HDL26035


HDL26035 is a Square D PowerPact H Frame 35 Amp 2 Pole Molded Case Circuit Breaker designed for reliable protection in commercial and industrial applications. This unit features a thermal magnetic trip unit and is UL 489 listed for safety and compliance. This molded case circuit breaker is built for 600VAC and 250VDC systems, with a 14kA interrupt rating at 600VAC. It is unit mount style and suitable for use in a variety of electrical distribution panels. The breaker is current limiting and offers protection against both overload and short circuit conditions.
  • Part Number: HDL26035
  • Manufacturer: Square D
  • Series/Frame: PowerPact H Frame
  • Amperage: 35 Amp
  • Poles: 2 Pole
  • Maximum Voltage: 600VAC / 250VDC
  • Interrupt Rating: 14kA @ 600VAC, 18kA @ 480VAC, 25kA @ 240VAC
  • Mounting Type: Unit Mount
  • Trip Unit: Thermal Magnetic
  • Certifications: UL 489, CSA, CE
  • Width: 4.09 Inches
  • Depth: 3.39 Inches
  • Height: 6.42 Inches
At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

  • Part Number: HDL26035
  • Manufacturer : Schneider Electric
  • Brand : Square D
  • Category : Circuit Breaker
  • Item Subcategory : Molded Case
  • Family : Powerpact
  • Type : HDL
  • Voltage : 600
  • Amperage : 35
  • Phase : 1
  • Poles : 2
  • AIC rating : 18kA@480V
  • Connection : Bolt-On
  • Functions : Long Time and Instantaneous Trip
  • Terminal Connection : Lug
  • Frame Size : H
  • Temp Rating : -13–158 °F (-25–70 °C)
  • MCM Size : Min. Wire Size 14 AWG (Cu/Al) Max. Wire Size 3/0 AWG (Cu/Al)
  • Protection : Thermal Magnetic

Product Data

  • UPC : 785901458937
  • GTIN : 00785901458937
  • Country of Origin : Mexico
  • Dimensions : 6.4 in (163 mm) x 4.09 in (104 mm) x 3.4 in (86 mm) (Height x Width x Depth)
  • Weight : 3.049
  • Standards : UL, CSA, NEMA, NOM-003-SCFI-2000, IEC 60947-2
  • Certification : UL, CSA, NOM
  • Wire Size : AWG 14...AWG 3/0 aluminium/copper terminal

Accesories

Part Manufacture Sub Category
S29371
S29451
S29450
S29390
S29410
