HDF36035 - Square D 35 Amp 3 Pole 600V PowerPact H Thermal Magnetic Circuit Breaker

HDF36035

HDF36035 is a Square D PowerPact H frame circuit breaker rated for 35 amps, 3 poles, and 600 volts designed for industrial power distribution protection.

This thermal magnetic circuit breaker features a 3-pole design with a 14kA interrupt rating at 600VAC and is bolt-on mounted. It provides reliable overload and short circuit protection with an 80% rated trip unit. The breaker is part of the PowerPact H series and is suitable for busbar or bolt-on applications in commercial and industrial electrical systems.

• Amperage: 35 Amps
• Voltage Rating: 600 VAC
• Poles: 3
• Interrupt Rating: 14kA at 600 VAC
• Frame/Series: PowerPact H
• Trip Unit: Thermal Magnetic
• Mounting Type: Bolt-On
• 80% Rated

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Additional Information

This item does not included Lugs. If you would like lugs please reach out to a sales rep with wiring specs and we can help you with the lugs part number.

Specifications

• Part Number: HDF36035
• Manufacturer : Schneider Electric
• Brand : Square D
• Category : Circuit Breaker
• Item Subcategory : Molded Case
• Family : Powerpact
• Type : HDF
• Voltage : 600
• Amperage : 35
• Phase : 3
• Poles : 3
• AIC rating : 18kA@480V
• Connection : Bolt-On
• Functions : LI - Long-Time and Instantaneous
• Frame Size : H Frame
• Temp Rating : 28-158 °F (-2-70 °C)
• Protection : Thermal Magnetic

Product Data

• UPC : 785901944621
• GTIN : 00785901944621
• Country of Origin : Mexico
• Dimensions : 6.4 in (163 mm) x 4.09 in (104 mm) x 3.4 in (86 mm) (Height x Width x Depth)
• Weight : 3.999
• Standards : UL, CSA, NEMA, NOM-003-SCFI-2000, IEC 60947-2
• Certification : UL, CSA, NOM
• Wire Size : AWG 14...AWG 3/0 aluminium/copper terminal
