HDA36100U43X - Schneider Electric PowerPact H 100A 3P 600V I-Line Plug-In Circuit Breaker 18kA AIC

HDA36100U43X

HDA36100U43X is a three-pole, 100 amp, 600 volt I-Line plug-in circuit breaker from Schneider Electric's PowerPact H series, designed for reliable protection in commercial and industrial power distribution systems. This breaker features an I-Line style plug-in mounting, making it easy to install and replace in compatible switchgear. It is equipped with a Micrologic 5.2A trip unit for advanced protection and monitoring, supporting long-time, short-time, and instantaneous (LSI) trip functions. The unit is rated for 18kA AIC at 480V and is UL listed for safety and performance.

• Part Number: HDA36100U43X
• Manufacturer: Schneider Electric
• Series/Frame: PowerPact H
• Amperage: 100A
• Voltage: 600V AC
• Poles: 3
• Mounting Type: I-Line Plug-In
• Interrupt Rating: 18kA AIC @ 480V
• Frame Size: H
• Series: PowerPact H
• Trip Unit: Micrologic 5.2A (LSI)
• Certifications: UL Listed

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: HDA36100U43X
• Manufacturer : Schneider Electric
• Brand : Schneider Electric
• Category : Circuit Breaker
• Item Subcategory : Molded Case
• Family : Powerpact
• Type : HDA
• Voltage : 600
• Amperage : 100
• Phase : 3
• Poles : 3
• AIC rating : 18kA@480V
• Connection : I-Line Style Plug-In
• Functions : LSI - Long-Time, Short-Time and Instantaneous
• Frame Size : H Frame
• Temp Rating : 28-158 °F (-2-70 °C)
• Protection : Solid State

Product Data

• UPC : 606487116069
• GTIN : 03606487116066
• Country of Origin : United States
• Dimensions : 6.4 in (163 mm) x 4.09 in (104 mm) x 3.4 in (86 mm) (Height x Width x Depth)
• Weight : 8.001
• Standards : UL, CSA, NEMA, NOM-003-SCFI-2000, IEC 60947-2
• Certification : UL, CSA, NOM
• Wire Size : AWG 14...AWG 3/0 aluminium/copper terminal
