HDA36060U44X - Square D PowerPact H 60A 3 Pole 600V I-Line Molded Case Circuit Breaker

HDA36060U44X

HDA36060U44X is a Square D PowerPact H series molded case circuit breaker designed for reliable protection in industrial and commercial power distribution systems. This 3-pole, 60A, 600V AC breaker features I-Line style plug-in mounting for easy installation and replacement. Equipped with a Micrologic 6.2A trip unit, it provides advanced electronic protection with LSIG (Long-Time, Short-Time, Instantaneous, and Ground Fault) trip functions. The breaker is suitable for ABC phase connection and offers solid-state trip technology for precise overcurrent and ground fault protection. This PowerPact H breaker is UL listed and suitable for reverse connection, making it a versatile solution for a wide range of applications. The unit is designed for use in panel-mounted I-Line bus systems and supports standard 80% or 100% rating. It is ideal for use in environments requiring high reliability and advanced protection features.

• 60A rated current
• 3 pole configuration
• 600V AC maximum voltage
• I-Line style plug-in mounting
• Micrologic 6.2A trip unit
• LSIG trip functions
• UL listed
• Suitable for reverse connection
• Standard 80% or 100% rating
• ABC phase connection
• Interrupt rating: 14kA at 600V AC
• Series: PowerPact H

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: HDA36060U44X
• Manufacturer : Schneider Electric
• Brand : Square D
• Category : Circuit Breaker
• Item Subcategory : Molded Case
• Family : Powerpact
• Type : HDA
• Voltage : 600
• Amperage : 60
• Phase : 3
• Poles : 3
• AIC rating : 18kA@480V
• Connection : I-Line Style Plug-In
• Functions : LSIG - Long-Time, Short-Time, Instantaneous and Ground Fault
• Terminal Connection : I-Line, Lug
• Frame Size : H
• Temp Rating : 28-158 °F (-2-70 °C)
• MCM Size : Min. Wire Size 14 AWG (Cu/Al) Max. Wire Size 3/0 AWG (Cu/Al)
• Protection : Solid State
• Phase Connection : ABC

Product Data

• UPC : 078590194392
• GTIN : 00785901943921
• Country of Origin : Mexico
• Dimensions : 6.4 in (163 mm) x 4.09 in (104 mm) x 3.4 in (86 mm) (Height x Width x Depth)
• Weight : 8.001
• Standards : UL, CSA, NEMA, NOM-003-SCFI-2000, IEC 60947-2
• Certification : UL, CSA, NOM
• Wire Size : AWG 14...AWG 3/0 aluminium/copper terminal
