2 Year Warranty Guaranteed
All items both Re-Certified, and New sold by Essential Electric include a 30 day return policy and a 2-year full warranty. This means that they are guaranteed to be free from defects for a full 2 years from the date that the product was shipped from our warehouse.
Product Questions? Contact Us
Product Info
- Manufacturer:Square D
- Sub-Category:Molded Case
Description
GJL36030
GJL36030 is a Square D 3 pole, 30 amp, 600 volt molded case circuit breaker designed for feed-thru mounting with a high interrupting capacity of 65kA at 480V.This thermal magnetic circuit breaker features long-time and instantaneous trip functions with a non-interchangeable trip unit. It supports 3 phase applications and includes line and load side lug terminals. The breaker is UL listed and has a magnetic trip range of 600-1200A, providing reliable protection and high interrupting capacity in industrial and commercial power distribution systems.
- Amperage: 30 Amp
- Voltage: 600 Volt AC
- Poles: 3
- Mounting Type: Feed-Thru
- Interrupt Rating: 65kA at 480V
- Series/Frame: GJL
- Trip Unit: Thermal Magnetic, Non-Interchangeable
- Magnetic Trip Range: 600-1200A
- UL Listed
- Line & Load Side Lug Terminals
- 3 Phase
Specifications
- Part Number: GJL36030
- Manufacturer : Square D
- Brand : Square D
- Category : Circuit Breaker
- Item Subcategory : Molded Case
- Family : GJL Series
- Type : GJL
- Voltage : 600
- Amperage : 30
- Phase : 3
- Poles : 3
- AIC rating : 65kA@480V
- Connection : Feed-Thru
- Functions : Long Time and Instantaneous Trip
- Protection : Thermal Magnetic
Product Data
- UPC : 785901849001
- GTIN : 00785901849001
- Weight : 3
- Wire Size : AWG 8, AWG 1/0 aluminium, AWG 14, AWG 1/0 copper
