Product Info
- Manufacturer:Square D
- Sub-Category:Molded Case
Description
GJL36015M03
GJL36015M03 is a 3 pole, 15 amp, 600 volt magnetic motor circuit protector designed for reliable motor protection in industrial and commercial applications. This Square D Mag-Gard circuit breaker features a feed-thru mounting style and a high interrupt rating for demanding environments. The GJL36015M03 offers a magnetic trip unit with a 45-165A magnetic range, suitable for motor circuit protection where precise overload and short-circuit protection is required. It is rated for 600Y/347V AC systems and features lugs on both ends for easy connection of #8 to #1/0 AWG aluminum or #14 to #1/0 AWG copper wire.
- Part Number: GJL36015M03
- Manufacturer: Square D
- Amperage: 15A
- Voltage: 600V AC
- Poles: 3
- Mounting Type: Feed-Thru
- Interrupt Rating: 65kA @ 480V
- Series/Frame: Mag-Gard GJL
- Frame Size: 3.54" W x 3.94" D x 4.72" H
- Trip Unit: Magnetic Only
- Connection Type: Lugs (Both Ends)
- Certifications: UL Listed
Specifications
- Part Number: GJL36015M03
- Manufacturer : Square D
- Brand : Square D
- Category : Circuit Breaker
- Item Subcategory : Molded Case
- Family : GJL Series
- Type : GJL
- Voltage : 600
- Amperage : 15
- Phase : 3
- Poles : 3
- AIC rating : 65kA@480V
- Connection : Feed-Thru
- Functions : I - Instantaneous
- Protection : Magnetic Only
Product Data
- UPC : 785901793601
- GTIN : 00785901793601
- Dimensions : Length 4 ft (1.22 m)
- Weight : 2
- Certification : UL, CSA
- Wire Size : AWG 8 to AWG 1/0 Aluminum, AWG 14 to AWG 1/0 Copper
