GF224N Siemens VBII Series Disconnect 240 ACV 200A Fusible Switch

GF224N

GF224N - Siemens 200A 2-pole 3-wire NEMA 1 general duty fusible safety switch rated for 240 VAC/250 VDC.This Siemens GF224N is a low voltage circuit protection general duty safety switch featuring mechanical lugs connection, single throw actuating element, and steel housing design. It provides disconnecting means for service entrance/loads with a 200A ampacity and surface mounting.

• Part Number: GF224N
• Manufacturer: Siemens
• Product Type: General Duty Safety Switch
• Amperage: 200A
• Voltage: 240 VAC / 250 VDC
• Poles: 2
• Wires: 3-wire
• Type: Fusible
• Enclosure: NEMA 1 (Type 1)
• Mounting: Surface
• Connection: Mechanical Lugs
• Actuator: Single Throw
• Material: Steel
• Certification: UL98

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: GF224N
• Manufacturer : Siemens
• Brand : Siemens
• Category : Switch
• Item Subcategory : Disconnect
• Section : Fusible
• Family : VBII Series
• Type : GF
• Voltage : 240 AC
• Amperage : 200
• Phase : 1
• Poles : 2
• AIC rating : 100kA@240V
• Temp Rating : -13¡F - 158¡F (-25¡C - 70¡C)
• Fuse Class : R
• Configuration : Single
• Switch Style : Fusible
• Nema Rating : Nema 1
• Compatible Frames : MEP

Product Data

• UPC : 783643148086
• GTIN : 00783643148086
• Country of Origin : Mexico
• Dimensions : 37.402 x 17.323 x 9.449 inch
• Weight : 41.491
• Temp Rating : -13¡F - 158¡F (-25¡C - 70¡C)
• Certification : UL listed
