FXD63B225 - Siemens 225 Amp 600V 3-Pole Molded Case Circuit Breaker, FD Frame, Thermal Magnetic Trip, 22kA Interrupt, UL 489, Bolt-On

FXD63B225

FXD63B225 is a Siemens Sentron Series molded case circuit breaker offering reliable 3-pole thermal magnetic protection at 225A and 600V.This bolt-on FXD frame breaker features a non-interchangeable trip unit with long-time and instantaneous functions, standard interrupting capacity rated at 35kA at 480V and 22kA at 600V, and is designed for 40 degree C operation. It is UL listed for reverse feed applications and provides robust circuit protection without installed lugs.

• Part Number: FXD63B225
• Manufacturer: Siemens
• Series/Frame: Sentron FXD6 / FXD
• Poles: 3
• Amperage: 225A
• Voltage: 600VAC
• Phase: 3
• Mounting Type: Bolt-On
• Trip Unit: Thermal Magnetic, LI (Long-Time/Instantaneous)
• Interrupt Rating: 35kA@480V, 22kA@600V
• Certifications: UL 489 Listed

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Additional Information

Lugs are not included and must be purchased separately

Specifications

• Part Number: FXD63B225
• Manufacturer : Siemens
• Brand : Siemens
• Category : Circuit Breaker
• Item Subcategory : Molded Case
• Family : Sentron Series
• Type : FXD
• Voltage : 600
• Amperage : 225
• Phase : 3
• Poles : 3
• AIC rating : 35kA@480V
• Connection : Bolt-On
• Functions : Long Time and Instantaneous Trip
• Frame Size : FD Frame
• Temp Rating : -13¡F - 158¡F (-25¡C - 70¡C)
• Breaker Type : Standard
• Protection : Thermal Magnetic

Product Data

• UPC : 783643211285
• GTIN : 00783643211285
• Country of Origin : Mexico
• Dimensions : 5.906 x 9.843 x 6.693 (W x H x D) Inches
• Weight : 8.869
• Panel Type : S4, P4, SPP, F1,FC1, FCII, CDP-5, CDP-6, SB1-3, S5, P5, SPP/FPP, F2
• Certification : UL, CSA, IEC
