Product Info
- Manufacturer:Siemens
- Sub-Category:Molded Case
Description
FXD63A150L
FXD63A150L is a Siemens Sentron Series molded case circuit breaker designed for reliable electrical protection in industrial and commercial applications.This 3 pole circuit breaker is rated for 150 amps and 600 volts, featuring a bolt-on mounting type. It provides a 22kA interrupting rating at 600V and includes ETI lugs for secure electrical connections. The breaker offers instantaneous trip protection and is part of the FXD frame series.
- Key Specifications
- Manufacturer: Siemens
- Part Number: FXD63A150L
- Series: Sentron FXD
- Amperage Rating: 150A
- Voltage Rating: 600V
- Poles: 3
- Interrupt Rating: 22kA at 600V
- Mounting Type: Bolt-On
- Trip Unit: Instantaneous Protection
- Connection Type: ETI Lugs
- Part Number: FXD63A150L
- Manufacturer : Siemens
- Brand : Siemens
- Category : Circuit Breaker
- Item Subcategory : Molded Case
- Family : Sentron Series
- Type : FXD
- Voltage : 600
- Amperage : 150
- Phase : 3
- Poles : 3
- AIC rating : 35kA@480V
- Connection : Feed-Thru
- Functions : I - Instantaneous
- Frame Size : FD Frame
- Temp Rating : -13¡F - 158¡F (-25¡C - 70¡C)
- Protection : Magnetic Only
- UPC : 783643005754
- GTIN : 00783643005754
- Country of Origin : Mexico
- Dimensions : 10.63 x 5.906 x 6.693 inch
- Weight : 21.738
- Certification : UL, CSA, IEC
