FH26080BC - Square D 80A 600V 2 Pole I-Line Style Plug-In Circuit Breaker, Thermal Magnetic, FH Frame

FH26080BC

FH26080BC is a Square D 2 pole, 80 amp, 600 volt thermal magnetic molded case circuit breaker designed for I-Line style plug-in mounting.This FH frame breaker features long-time and instantaneous trip functions, providing reliable protection with a high interrupting rating of up to 65kA at 240V and 25kA at 480V. It is UL and CSA approved for use in power distribution applications and supports wire sizes from 14 to 1/0 AWG copper or aluminum. The breaker is suitable for single-phase systems and installs easily in I-Line panelboards and switchboards.

Key Specifications
• Manufacturer: Square D
• Part Number: FH26080BC
• Amperage: 80 Amps
• Voltage Rating: 600 VAC, 250 VDC
• Poles: 2
• Frame Type: FH
• Mounting Type: I-Line Style Plug-In
• Interrupting Rating: 65 kA at 240 VAC, 25 kA at 480 VAC, 18 kA at 600 VAC, 10 kA at 250 VDC
• Trip Unit: Thermal Magnetic with Long-Time and Instantaneous Functions
• Approvals: UL 489, CSA
• Wire Size Range: 14 to 1/0 AWG Copper or Aluminum
At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.


Specifications

• Part Number: FH26080BC
• Manufacturer : Schneider Electric
• Brand : Square D
• Category : Circuit Breaker
• Item Subcategory : Molded Case
• Family : I-Line
• Type : FH
• Voltage : 600
• Amperage : 80
• Phase : 1
• Poles : 2
• AIC rating : 25kA@480V
• Connection : I-Line Style Plug-In
• Functions : LI - Long-Time and Instantaneous
• Frame Size : F Frame
• Protection : Thermal Magnetic



Product Data

• UPC : 785901338116
• GTIN : 00785901338116
• Country of Origin : Mexico
• Dimensions : 6.4 in (162.6 mm) x 3 in (76.2 mm) x 4.13 in (104.90 mm) (Height x Width x Depth)
• Weight : 6
• Wire Size : AWG 14...AWG 1/0 copper)1, AWG 12...AWG 1/0 aluminium)1
