FH26015AB - Square D 15 Amp 600V 2 Pole FH Series Thermal Magnetic Circuit Breaker

FH26015AB

FH26015AB is a Square D 2 pole thermal magnetic molded case circuit breaker rated for 15 amps and 600 volts AC. It features an I-Line style plug-in connection and is designed for reliable power distribution protection.This FH series circuit breaker supports 600VAC and 250VDC voltage ratings with a 25kA interrupting rating at 480V. It includes long time and instantaneous trip functions, UL and CSA certifications, and is suitable for use in panelboards and switchboards. The breaker accepts 14 to 4 AWG copper or aluminum wire and is rated for operation at 40°C.

Key Specifications
• Amperage: 15 Amps
• Voltage: 600VAC, 250VDC
• Poles: 2
• Series/Frame: FH
• Mounting Type: I-Line Style Plug-In
• Interrupting Rating: 25kAIC @ 480V
• Trip Unit: Thermal Magnetic with Long Time and Instantaneous Trip
• Certifications: UL, CSA, NOM, IEC, CCC, CE
• Terminal Wire Size: 14 to 4 AWG Copper/Aluminum
• Temperature Rating: 40°C

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: FH26015AB
• Manufacturer : Schneider Electric
• Brand : Square D
• Category : Circuit Breaker
• Item Subcategory : Molded Case
• Family : I-Line
• Type : FH
• Voltage : 600
• Amperage : 15
• Phase : 1
• Poles : 2
• AIC rating : 25kA@480V
• Connection : I-Line Style Plug-In
• Functions : Long Time and Instantaneous Trip
• Frame Size : F Frame
• Temp Rating : -13–158 °F (-25–70 °C)
• Protection : Thermal Magnetic

Product Data

• UPC : 785901254676
• GTIN : 00785901254676
• Country of Origin : Mexico
• Dimensions : 6.4 in (162.6 mm) x 3 in (76.2 mm) x 4.13 in (104.90 mm) (Height x Width x Depth)
• Weight : 6
• Certification : UL, CSA, NOM, IEC, CCC, CE
• Wire Size : 14 to 4 AWG AL/CU
