FDB3070L - Cutler Hammer 70A 600V 3-Pole F-Frame Molded Case Circuit Breaker

FDB3070L

FDB3070L is a Cutler Hammer Series C molded case circuit breaker designed for industrial and commercial power distribution applications.

This 3-pole breaker features a 70 ampere rating, 600 volt AC maximum voltage, and a fixed thermal magnetic trip unit. It is an F-frame type with feed-thru connection and offers a 14kA interrupting rating at 480 volts AC. The breaker supports long-time and instantaneous trip functions and is UL and CSA certified for safety and reliability.

Key Specifications
• Manufacturer: Cutler Hammer (Eaton)
• Series: C, Type FDB
• Amperage: 70A
• Voltage Rating: 600 VAC, 250 VDC
• Poles: 3
• Interrupt Rating: 14kA at 480 VAC, 18kA at 240 VAC
• Trip Unit: Fixed Thermal Magnetic (Long-Time and Instantaneous)
• Frame Type: F-Frame
• Mounting Type: Panel Mount, Feed-Thru Connection
• Certifications: UL, CSA, CE
• Dimensions: 6" H x 4.13" W x 3.38" D
• Weight: 4.5 lbs

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: FDB3070L
• Manufacturer : Cutler Hammer
• Brand : Cutler Hammer
• Category : Circuit Breaker
• Item Subcategory : Molded Case
• Family : Series C
• Type : FDB
• Voltage : 600
• Amperage : 70
• Phase : 3
• Poles : 3
• AIC rating : 14kA@480V
• Connection : Feed-Thru
• Functions : LI - Long-Time and Instantaneous
• Frame Size : F Frame
• Protection : Thermal Magnetic

Product Data

• UPC : 786679305980
• GTIN : 00786679305980
• Country of Origin : Dominican Republic
• Dimensions : 3.38 in x 6 in x 4.13 in (Length/Depth x Height x Width)
• Weight : 4.5
• Certification : UL Listed
