FDB3015 - Cutler Hammer Series C 3P 15A 600V 14kAIC F-Frame Molded Case Circuit Breaker, Thermal Magnetic Trip, Panel Mount, UL Listed

FDB3015

FDB3015 is a Cutler Hammer Series C molded case circuit breaker designed for reliable protection in industrial power distribution applications.

This three-pole, 15 ampere breaker features a thermal magnetic trip unit, F-frame construction, and a high interrupting capacity. It is rated for 600V AC and 250V DC operation, with a 14kA interrupting rating at 480V AC. The FDB3015 is panel-mounted, includes line and load side terminals, and is UL listed for safety and compliance.

Key Specifications
• Part Number: FDB3015
• Manufacturer: Cutler Hammer (Eaton)
• Amperage: 15A
• Voltage: 600V AC, 250V DC
• Poles: 3
• Mounting Type: Panel mount
• Interrupt Rating: 14kA at 480V AC, 18kA at 240V AC
• Series/Frame: Series C, F-frame
• Trip Unit: Fixed thermal, fixed magnetic (thermal magnetic)
• Terminals: Line and load side, standard pressure
• Certifications: UL Listed, CSA
• Dimensions: 6" H x 4.13" W x 3.38" D
• Weight: 4.5 lbs

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: FDB3015
• Manufacturer : Cutler Hammer
• Brand : Cutler Hammer
• Category : Circuit Breaker
• Item Subcategory : Molded Case
• Family : Series C
• Type : FDB
• Voltage : 600
• Amperage : 15
• Phase : 3
• Poles : 3
• AIC rating : 14kA@480V
• Connection : Bolt-On
• Functions : LI - Long-Time and Instantaneous
• Frame Size : F Frame
• Protection : Thermal Magnetic

Product Data

• UPC : 786679305829
• GTIN : 00786679305829
• Country of Origin : Dominican Republic
• Dimensions : 3.38 in x 6 in x 4.13 in (Length/Depth x Height x Width)
• Weight : 4.5
• Certification : UL Listed
