2 Year Warranty Guaranteed
All items both Re-Certified, and New sold by Essential Electric include a 30 day return policy and a 2-year full warranty. This means that they are guaranteed to be free from defects for a full 2 years from the date that the product was shipped from our warehouse.
Product Questions? Contact Us
Product Info
- Manufacturer:Eaton
- Sub-Category:Molded Case
Description
FD4225BP10
FD4225BP10 is a Series C molded case circuit breaker designed for reliable protection in commercial and industrial power distribution systems. This Eaton breaker features a 225A amperage rating, 600V AC voltage rating, and a four-pole configuration for three-phase applications. The FD4225BP10 is a bolt-on mounting type, making it suitable for panelboard installations where secure attachment is required. It utilizes a thermal magnetic trip unit for dependable overcurrent protection and is built with an F-frame for durability and compatibility with Series C systems. The breaker is UL listed and offers high interrupt ratings for safety in demanding environments. This molded case circuit breaker is engineered for use in a wide range of electrical distribution panels, providing robust protection for motors, transformers, and other critical loads. The bolt-on design ensures a solid connection and easy installation, while the thermal magnetic trip mechanism delivers precise response to overloads and short circuits. The Series C platform is known for its reliability and compatibility with a variety of accessories and enclosures.
- Part Number: FD4225BP10
- Manufacturer: Eaton
- Series: Series C
- Frame: F-Frame
- Amperage Rating: 225 A
- Voltage Rating: 600 Vac, 250 Vdc
- Number of Poles: 4
- Mounting Type: Bolt-On
- Interrupt Rating: 65 kAIC at 240 Vac, 35 kAIC at 480 Vac
- Frequency Rating: 50 to 60 Hz
- Terminals: Line and Load
- Certifications: UL Listed
Specifications
- Part Number: FD4225BP10
- Manufacturer : Eaton
- Brand : Cutler Hammer
- Category : Circuit Breaker
- Item Subcategory : Molded Case
- Family : Series C
- Type : FD
- Voltage : 600
- Amperage : 225
- Phase : 3
- Poles : 4
- AIC rating : 25kA@480V
- Connection : Bolt-On
- Functions : LI - Long-Time and Instantaneous
- Frame Size : F Frame
- Protection : Thermal Magnetic
Product Data
- Weight : 5
