Product Info
- Manufacturer:Eaton
- Sub-Category:Molded Case
Description
FD3020LBP10
FD3020LBP10 is a Series C F-frame molded case circuit breaker from Eaton, designed for reliable protection in commercial and industrial power distribution systems.This three-pole circuit breaker features a fixed thermal and fixed magnetic trip unit, providing consistent overcurrent protection. It is rated for 20A continuous current and operates at up to 600VAC or 250VDC. The breaker is suitable for load-side mounting and is built to meet demanding electrical safety standards.
- Series C F-frame
- Three-pole
- 20A amperage rating
- 600VAC / 250VDC voltage rating
- 65 kAIC interrupt rating at 240VAC
- 35 kAIC interrupt rating at 480VAC
- Fixed thermal / fixed magnetic trip
- Load-side mounting
- UL Listed
- 50/60 Hz frequency
Specifications
- Part Number: FD3020LBP10
- Manufacturer : Eaton
- Brand : Cutler Hammer
- Category : Circuit Breaker
- Item Subcategory : Molded Case
- Family : Series C
- Type : FD
- Voltage : 600
- Amperage : 20
- Phase : 3
- Poles : 3
- AIC rating : 35kA@480V
- Connection : Feed-Thru
- Functions : LI - Long-Time and Instantaneous
- Frame Size : F Frame
- Protection : Thermal Magnetic
Product Data
- Weight : 2
