Description
FD1100L
FD1100L is a 100 amp, 1 pole molded case circuit breaker from Eaton Cutler Hammer, designed for reliable circuit protection in industrial and commercial applications.This Eaton Series C complete molded case circuit breaker features an F-frame design with fixed thermal and magnetic trip units. It supports a maximum voltage of 347 VAC and 125 VDC, with interrupt ratings of 35 kAIC at 277 VAC and 18 kAIC at 347 VAC. The breaker is suitable for feed-thru mounting and operates at 50/60 Hz frequency.
- Amperage: 100 Amp
- Poles: 1
- Maximum Voltage: 347 VAC / 125 VDC
- Interrupt Rating: 35 kAIC @ 277 VAC, 18 kAIC @ 347 VAC
- Series/Frame: C Series, F Frame
- Trip Unit: Fixed Thermal / Fixed Magnetic
- Mounting Type: Feed-Thru
- Frequency: 50/60 Hz
- Manufacturer: Eaton Cutler Hammer
- Certifications: UL Listed, CSA Certified
Specifications
- Part Number: FD1100L
- Manufacturer : Eaton
- Brand : Cutler Hammer
- Category : Circuit Breaker
- Item Subcategory : Molded Case
- Family : Series C
- Type : FD
- Voltage : 277
- Amperage : 100
- Phase : 1
- Poles : 1
- AIC rating : 35kA@277V
- Connection : Feed-Thru
- Functions : LI - Long-Time and Instantaneous
- Frame Size : F Frame
- Protection : Thermal Magnetic
Product Data
- UPC : 786679398340
- GTIN : 00786679398340
- Country of Origin : Dominican Republic
- Dimensions : 3.38 in x 6 in x 1.38 in (Length/Depth x Height x Width)
- Weight : 4.5
- Certification : UL Listed
