FD1100 - Cutler Hammer 100A 277V 1-Pole F-Frame Molded Case Circuit Breaker

FD1100

This Eaton Series C F-frame breaker provides fixed thermal and magnetic trip protection with a single pole configuration. It supports a 35 kA interrupt rating at 277 VAC and 18 kA at 347 VAC, ensuring high fault current interruption capability. The breaker is bolt-on mounted and UL listed, ideal for panel installations requiring robust overload and short circuit protection.

Key Specifications
• Amperage: 100 A
• Voltage: 277 VAC, 125 VDC
• Poles: 1
• Frame Type: F-Frame
• Mounting Type: Bolt-On
• Interrupt Rating: 35 kAIC at 277 VAC, 18 kAIC at 347 VAC
• Trip Unit: Fixed Thermal Magnetic
• Series: Eaton Series C
• Phase: Single Phase
• Frequency: 50/60 Hz
• Certifications: UL Listed
• Weight: 2 lb

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.




Specifications

• Part Number: FD1100
• Manufacturer : Cutler Hammer
• Brand : Cutler Hammer
• Category : Circuit Breaker
• Item Subcategory : Molded Case
• Family : Series C
• Type : FD
• Voltage : 277
• Amperage : 100
• Phase : 1
• Poles : 1
• AIC rating : 35kA@277V
• Connection : Bolt-On
• Functions : Long Time and Instantaneous Trip
• Frame Size : F Frame
• Temp Rating : -13–158 °F (-25–70 °C)
• Protection : Thermal Magnetic



Product Data

• UPC : 786679398265
• GTIN : 00786679398265
• Country of Origin : Dominican Republic
• Dimensions : 3.38 in x 6 in x 1.38 in (Length/Depth x Height x Width)
• Weight : 2 lb
• Certification : UL Listed
