FAZ-C3/2-NA-DC - Eaton 3A 125Vdc Two-Pole Industrial Miniature Circuit Breaker

FAZ-C3/2-NA-DC

FAZ-C3/2-NA-DC is an Eaton FAZ branch protector industrial miniature circuit breaker designed as a supplementary protector for applications with medium levels of inrush current. This two-pole thermal magnetic breaker provides reliable circuit protection for small transformers and pilot devices with a C curve trip characteristic and 5-10X thermal multiplier rating. Key Specifications

• Amperage Rating: 3 A
• Voltage Rating: 125 Vdc per pole
• Number of Poles: Two-pole
• Interrupt Rating: 10 kAIC
• Circuit Protection: C Curve
• Trip Type: 5-10X /n thermal magnetic
• Frequency Rating: 50-60 Hz
• Terminal Type: Screw terminals
• Mounting: 35mm DIN Rail
• Certifications: UL 489, CSA Std. C22.2 No. 235
• Product Dimensions: 1.4 in L x 2.97 in W x 4.13 in H
• Weight: 1 lb

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: FAZ-C3/2-NA-DC
• Manufacturer : Eaton
• Brand : Eaton
• Category : Circuit Breaker
• Item Subcategory : Molded Case
• Family : FAZ Series
• Type : FAZ-NA
• Voltage : 125
• Amperage : 3
• Phase : 1
• Poles : 2
• AIC rating : 10kA@125V
• Connection : Feed-Thru
• Functions : LI - Long-Time and Instantaneous
• Protection : Thermal Magnetic

Product Data

• UPC : 4015081340408
• GTIN : 04015081340408
• Country of Origin : Spain
• Dimensions : 1.4 in x 4.13 in x 2.97 in (Length/Depth x Height x Width)
• Weight : 1
• Certification : CSA Std. C22.2 No. 235, UL 489
