FAZ-C3/2-NA - Eaton 3A 2-Pole 277/480V C Curve Miniature Circuit Breaker UL 489

FAZ-C3/2-NA

FAZ-C3/2-NA is a 3 amp, two-pole Eaton miniature circuit breaker designed for medium inrush current applications.This Eaton FAZ branch protector features a C curve trip unit, 10 kA interrupt rating at 277/480 volts AC, and screw terminals for secure mounting. It is UL 489 and CSA certified, suitable for protecting small transformers, pilot devices, and control circuits. The breaker is DIN rail mountable and provides reliable current limiting protection with thermal magnetic trip characteristics.

• Amperage: 3 A
• Voltage Rating: 277/480 VAC
• Number of Poles: 2
• Trip Curve: C Curve (medium inrush)
• Interrupt Rating: 10 kAIC
• Mounting Type: DIN rail
• Terminal Type: Screw terminals
• Certifications: UL 489, CSA Std. C22.2 No. 235
• Frequency: 50-60 Hz
• Application: Suitable for medium inrush current devices
• Current Limiting: Yes
• Warranty: 1 year

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: FAZ-C3/2-NA
• Manufacturer : Eaton
• Brand : Eaton
• Category : Circuit Breaker
• Item Subcategory : Molded Case
• Family : FAZ Series
• Type : FAZ-NA
• Voltage : 480
• Amperage : 3
• Phase : 1
• Poles : 2
• AIC rating : 10kA@277/480V
• Connection : Feed-Thru
• Functions : LI - Long Time and Instantaneous
• Terminal Connection : Screw Clamp
• Frame Size : 40A/FAZ
• Temp Rating : -13–158 °F (-25–70 °C)
• MCM Size : Min. Wire Size 18 AWG Max. Wire Size 6 AWG
• Protection : Thermal Magnetic

Product Data

• UPC : 015081020379
• GTIN : 04015081020379
• Country of Origin : Spain
• Dimensions : 1.4 in x 4.13 in x 2.97 in (Length/Depth x Height x Width)
• Weight : 1 lb
• Standards : CSA Certified, IEC 60947-2, UL 489 Listed
• Certification : CSA Certified, IEC 60947-2, UL 489 Listed
• Wire Size : 18 to 6 AWG, 18 to 10 AWG
